maXpeedingrods Coilovers compatible for VW Polo MK5 6R/6C compatible for Audi A1 8X compatible for Seat MK4 6J

This MaXpeedingRods part is suitable for Audi, Volkswagen, Seat applications where stated. Always check part number, year of manufacture, engine code and fitment before ordering.

Advantages

• Based on original MaXpeedingRods product information
• Suitable for direct replacement or performance upgrade

Application, specifications and compatibility

Introductionma Xpeedingrods-B1 series is ideal for those who want to change the old worn-out strut but improve handling at the same time. It features height adjustable and maintains the OE ride quality to the greatest extent.Application Suitable for VW POLO V (6R_, 6C_) 03 / 2009-hatchback

suitable for AUDI A1 (8X) 8X1, 8XK 05 / 2010-10 / 2018 hatchback

suitable for AUDI A1 Sportback (8X) 8XA, 8XF 09 / 2011-10 / 2018 hatchback

suitable for SEAT IBIZA IV (6J5, 6P1) 03 / 2008-12 / 2017 hatchback

suitable for SEAT IBIZA IV SPORTCOUPE (6J1, 6P5) 06 / 2008-12 / 2018 coupe

suitable for SEAT IBIZA IV ST (6J8, 6P8) 03 / 2010-07 / 2016 station wagon

suitable for SKODA FABIA NJ 2014+Specifications Top mounts: Front and rear OE top mounts required

Damping adjustable: Not available

Camber adjustable: Not available

Height adjustable: Yes, lowering 0-25mm depending on the vehicle models

Spring rate Front: 8 kg/mm (448 lbs/in)

Spring rate Rear: 3.5 kg/mm (196 lbs/in)

Front spring inner diameter: 62 mm

Rear spring inner diameter: 63-64 mm

Spring length Front: 170 mm

Spring length Rear: 225 mm

Help spring rate Front: 1 kg/mm (56 lbs/in)

Help spring length Front: 102 mm

Spring Preload advised: 7-10 mm

Color: Black body with black spring Package included Package included：

2x Front coil-overs

2x Rear coil-overs

2x C spanners Dimension Package size : 70*50*20 cm

Weight: 20000 g Features1.0-25mm(depends on vehicle models) lower height adjustable

2. Dust boot, solid rubber bump stops

3. Weight Saving Aluminum Components And heavy duty Steel Lower Mount Brackets

4. Simple install,Easy to adjust.

5. Use the vehicle's original upper mounts (not included in our product kit).Note1. All modifications must be installed by licensed mechanics and in compliance with your local modification regulations.

2. Please ensure all components are tightened with correct torque specifications (which can be found in the vehicle service manual)before and after installation. Any loose nuts, bolts, or locks will cause noise. Do check and tighten before serious problems happen.

3. Impact wrench is prohibited during the installation, it will loosen or damage the product.

4. Examine the clearance between tires and suspension. ( The minimum clearance should be 4mm, otherwise, you need to add wheel spacers. Caution: It is not sufficient with torsion beam trailing arm axles)

5. We suggest regular maintenance for the coil-over, spray with some WD40 every 3-4 months will keep it smooth and clean, which helps to extend the lifetime.
