Product Description

Air suspension with compressor and controller kit for the rear axle, suitable for various pick-ups.

Suitable for:

• Ford F-250 4WD RWD 1999-2007
• Ford F250 1999 Base Model
• Ford F250 Super Cab 1999 4WD RWD
• Ford F250 1999-2004 4WD RWD
• Ford F250 Ranch 2005-2007 4WD RWD
• Ford F250 Lariat 2005-2007 4WD RWD
• Ford F250 XL 2005-2007 4WD RWD
• Ford F250 XLT 2005-2007 4WD RWD
• Ford F-350 4WD RWD 1999-2007
• Ford F350 1999-2004 4WD RWD
• Ford F350 Ranch 2005-2007 4WD RWD
• Ford F350 Lariat 2005-2007 4WD RWD
• Ford F350 XL 2005-2007 4WD RWD
• Ford F350 XLT 2005-2007 4WD RWD

Specifications

• Condition: Brand New
• Spring Type: Leaf Spring
• Position: Rear
• Minimum Pressure: 5 PSI
• Maximum Pressure: 100 PSI
• Integrated Jounce Bumper: Yes
• Material: Toughened Natural Rubber
• Air Spring Load Capacity: up to 5000 LBS
• Air Spring Mounting Height: 180 mm
• Air Spring Stroke: 100 mm
• Max. Extended: 200 mm
• Min. Compressed: 100 mm
• Maximum Air Pressure: 100 psi
• Recommended Operating Pressure: 5-70 PSI

Scope of delivery

Air Suspension Bag Kit: 2x high-quality double-bellow air springs, 4x upper and lower mounting brackets, including all necessary brackets and mounting hardware. Air Suspension Compressor Controller Kit: 1x 12V MaXpeedingrods air compressor (black), 1x pressure gauge panel (up/down push buttons), 1x air line φ6*1 (6m), 1x wiring harness (2.5m) black, 1x wiring harness (8.5m) red, 1x relay wiring (1m), 3x T-connectors and some other accessories.

Features

• Maintains proper ride height
• Reduces vehicle rear-end sway during towing
• Prevents sagging of main springs due to constant load compression
• Increases safety and comfort when carrying heavy loads
• Two adjustable secondary air springs provide level control up to 5,000 lbs per axle for leaf spring vehicles
• Air pressure in the air spring bag can be monitored and adjusted from the driver's seat
• Suitable for light to medium duty applications and occasional towing
• Includes onboard air compressor, single-gauge dashboard panel, air lines and mounting hardware
• Single-path control for adjusting a pair of air springs
• Strict quality control for long-term use without damage
• Wiring harness has flame retardant properties
• Air compressor with waterproof housing

Please note: only works on trucks equipped with B&W Hitch 1105 or 1199R in the 49-inch position. Suitable for many 3/4-ton and 1-ton pickup trucks and vans.

Check fitment

Always check the original OEM part number, year of manufacture, engine code and the version of your vehicle before ordering, as there may be differences per version. If you are unsure whether this part fits your vehicle, please feel free to contact us before purchasing.
