Product Description

This 12V diesel air heater (parking heater) is designed for the cabins of trucks, vans, motorhomes, yachts/boats, and other vehicles.

Specifications

• Power: 2KW - 5KW
• Rated voltage: 12 V
• Switch type: LCD switch
• Fuel: Diesel
• Fuel consumption: 0.2 - 0.5 L/h
• Tank capacity: 10 L
• Heater operating temperature: -40°C ~ +50°C
• Oil pump operating temperature: -40°C ~ +40°C
• Dimensions: 39 x 14.5 x 14.5 cm
• Heater color: Black & red
• Material: Metal & plastic

Scope of delivery

1x parking heater, 1x LCD switch, 1x remote control, 1x muffler (for cars only), 1x diesel tank (10 L), 1x main wiring harness, 1x T-piece, 1x oil pump, 1x oil pump connection cable, 1x filter, 1x oil line, 1x air intake pipe (aluminum alloy, 50 cm), 1x exhaust pipe (stainless steel, 60 cm), 1x gasket, 1x reducer T-piece, 2x clamp, 1x oil pump clamp, 1x air intake pipe clamp, 1x exhaust clamp, 2x air intake pipe fixing clamp, 2x exhaust fixing clamp, 6x oil pipe coupling, 2x oil pipe clamp, 4x washer, 4x nut, 4x self-tapping screw, 1x nylon cable tie, 1x oil suction pipe, 1x air intake cap, 1x metering oil pump.

Features

• Smooth, automatic temperature control with pre-settable temperature
• Low fuel and power consumption, suitable for long-term use
• Large range for more comfort, quiet operation at night
• Fully electronic microprocessor control with continuous monitoring and diagnostic system
• Power mode to shorten warm-up time
• Quiet operation, low noise during operation
• Low maintenance, easy to maintain
• Can be operated while on the go
• Runs on fuel from the vehicle's own tank (diesel only)
• Compact design for easy, space-saving installation, even under the floor
• Independent heating: blows warm air independently of the engine, without wear or carbon deposits, which can extend engine life
• Intelligent overheating sensor prevents dry running and maintains a constant temperature
• Can remove window frost
• Low emissions and low fuel consumption, meets Euro IV engine emission requirements

Please note

During installation, the fixed rear wall must be sealed and separated from the body panel, to prevent combustion gases from entering the cabin through gaps. The length of the exhaust pipe must be at least 30 cm. The exhaust opening must be placed firmly in the clear space and must not point in the direction of travel. Due to manual measurement, a deviation of 1-3 cm may occur. Professional installation is recommended.

Check fitment

Before ordering, always check the original OEM part number, year of manufacture, engine code, and the version of your vehicle, as there may be differences depending on the version. Are you unsure if this part fits your vehicle? Feel free to contact us before purchase.
