2x Triple Bellows Air Bag 2600 lbs Standard Air Suspension suitable for Light Duty Mini-trucks
2x Triple Bellows Air Bag 2600 lbs Standard Air Suspension suitable for Light Duty Mini-trucks
- * Concurrerende prijs
- * Sneller verzenden
- * Staat: 100% nieuw!
- * Garantie: 1 jaar garantie op eventuele fabricagefouten
- * Accessoires: je ontvangt precies zoals op de afbeelding hierboven!
Product Description
This set of 2 air spring bags (Triple Bellows, 2600 LBS) is intended as an aftermarket replacement for the original rear air suspension.
Suitable for:
- Most buses, trucks, trailers, mini-trucks, light-duty vehicles and subframe applications (universal)
Specifications
- Stroke/collapsed: 220 mm / 8.6"
- Maximum height: 330 mm / 13"
- Minimum height: 110 mm
- Design height: 250 mm / 9.8"
- Top plate diameter: 131 mm
- Port size: 1/2-14NPT single port
- Mounting hole size: 3/8-16UNC
- Independent test pressure: minimum 290 psi
- Recommended working range: 0 - 170 psi
- Air spring bag capacity: 2600 LBS/side
- Condition: Brand new
- Installation position: Rear, front, right, left
- Quantity: 2 air spring bags
Scope of delivery
2x air spring bag
Features
- OEM product, easy to install
- Tested over 5,000,000 times: durable and safe
- 24-hour air tightness test ≤0.02MPa: guarantee of air tightness
- Temperature range ≥ -40°C / ≤ 70°C, premium natural rubber material
- Allows vehicles to handle irregular or heavy loads and helps maintain vehicle control
- CE qualified
Check fitment
Always check the original OEM part number, year of manufacture, engine code and the version of your vehicle before ordering, as there may be differences per version. Are you unsure if this part fits your vehicle? Feel free to contact us before purchasing.
