4pcs Suspension Kit for Infiniti M35x M45x 06-10 AWD Adjustable Shock Absorbers
4pcs Suspension Kit for Infiniti M35x M45x 06-10 AWD Adjustable Shock Absorbers
- * Concurrerende prijs
- * Sneller verzenden
- * Staat: 100% nieuw!
- * Garantie: 1 jaar garantie op eventuele fabricagefouten
- * Accessoires: je ontvangt precies zoals op de afbeelding hierboven!
Product Description
Adjustable threaded chassis (coilover kit) with adjustable damping and ride height for the Infiniti M35x.
Suitable for:
- Infiniti M35x, 06-10, AWD
- Infiniti M45x, 06-10, AWD
- Infiniti G35x, 03-08, AWD
- Infiniti G37x, 08-13, AWD
Please note: not suitable for the RWD model. The rear is a true coilover construction, not a separate spring/damper combination.
Specifications
- Upper mounting: front and rear standard rubber top mounts
- Damping adjustable: yes, 24 positions rebound damping
- Camber adjustable: not available
- Ride height adjustable: yes, 25-75 mm lowering depending on the model
- Spring stiffness front: 12 kg/mm (672 lbs/in)
- Spring stiffness rear: 10 kg/mm (560 lbs/in)
- Spring length front: 160 mm
- Spring length rear: 200 mm
- Inner diameter spring front: 62 mm
- Inner diameter spring rear: 62 mm
- Recommended preload: 7-10 mm
- Color: gold housing with black spring
Scope of delivery
2x front coilovers, 2x rear coilovers, 2x C-wrenches, 1x hex key. Packaging dimensions 64x50x20 cm, weight approx. 22.900 g.
Features
- Ride height adjustable from 25-75 mm (depending on model) for a lower center of gravity and sportier appearance
- 24 positions adjustable damping, from comfortable to track use
- Adjustable spring preload
- Adjustable camber plate and spherical bearing top mount for sharper steering response (on some models)
- CNC machined aluminum top mounts and lock nuts for strength and weight savings
- Heavy-duty steel lower mounting points for durability and reliability
- High-quality tension spring, tested for 600,000 load cycles
- All inserts fitted with rubber protective covers
- Twin-tube construction for excellent control under virtually all driving conditions
- Corrosion-resistant finish: anodized aluminum and powder-coated steel
Please note: have all adjustments carried out by an authorized mechanic and in accordance with local regulations. Check all fasteners for correct torque before and after installation. Do not use an impact wrench during installation. Check the clearance between tires and suspension (minimum 4 mm, otherwise use wheel spacers; not sufficient for torsion beam rear suspension). Periodic maintenance (e.g., WD40 every 3-4 months) is recommended.
Always check the original OEM part number, year of manufacture, engine code, and version of your vehicle before ordering, as differences may exist per version. Are you unsure whether this part fits your vehicle? Feel free to contact us before purchasing.
