Application:

Compatible for Ford Transit Tourneo Bus 2.2 TDCi 103KW 2007-2014
Compatible for Ford Transit Tourneo Bus 2.2 92KW compatible for FWD CYFA, CYFB, CYFC, CYFD 2011-2014
Compatible for Ford Tourneo Custom V362 Bus (F3) 2.2 TDCi 92KW compatible for FWD CYF4, CYFF 2012-2015
Compatible for Ford Tourneo Custom V362 Bus (F3) 2.2 TDCi 74KW compatible for FWD DRF4, DRFF, DRFG 2012-2015
Compatible for Ford Tourneo Custom V362 Bus (F3) 2.2 TDCi 114KW compatible for FWD CVFF 2012-2015
Compatible for Ford Transit Custom V362 Van (FY, FZ) 2.2 TDCi 74KW DRF4, DRFF, DRFG 2012-2016
Compatible for Ford Transit Custom V362 Van (FY, FZ) 2.2 TDCi 114KW CVFF 2012-2016
Compatible for Ford Transit Custom V362 Van (FY, FZ) 2.2 TDCi 92KW CYF4, CYFF 2012-2016
Compatible for Ford Transit V363 Van (FCD, FDD) 2.2 TDCi 114KW compatible for FWD CVF5 2013-2018
Compatible for Ford Transit V363 Van (FCD, FDD) 2.2 TDCi 74KW compatible for FWD DRF5, DRFF, DRFG 2013-2018
Compatible for Ford Transit V363 Van (FCD, FDD) 2.2 TDCi 92KW compatible for FWD CY14, CYF5, CYFG, USF6 2013-2018
Compatible for Ford Transit V363 Bus (FAD, FBD) 2.2 TDCi 92KW compatible for FWD CY14, CYF5, CYFG, USF6 2013-2018
Compatible for Ford Transit V363 Bus (FAD, FBD) 2.2 TDCi 74KW compatible for FWD DRF5, DRFF, DRFG 2013-2018
Compatible for Ford Transit V363 Platform/Chassis (FED, FFD) 2.2 TDCi compatible for FWD 114KW 2013-2018
Compatible for Ford Transit V363 Platform/Chassis (FED, FFD) 2.2 TDCi 74KW compatible for FWD DRF5, DRFF, DRFG 2013-2018
Compatible for Ford Transit V363 Platform/Chassis (FED, FFD) 2.2 TDCi 92KW compatible for FWD CY14, CYF5, CYFG, USF6 2013-2018
Compatible for Ford Transit Platform/Chassis (FM_, FN_, FF_) 2.2 TDCi 74KW compatible for FWD DRFA, DRFB, DRFC, DRFD, DRFE 2011-2014
Compatible for Ford Transit Platform/Chassis (FM_, FN_, FF_) 2.2 TDCi 92KW compatible for FWD CYFA, CYFB, CYFC, CYFD 2011-2014
Compatible for Ford Transit Platform/Chassis (FM_, FN_, FF_) 2.2 TDCi 103KW PGFA, PGFB, UHFA, UHFB, UHFC 2007-2014
Compatible for Ford Transit Bus (FD_, FB_, FS_, FZ_, FC_) 2.2 TDCi 92KW compatible for FWD CYFA, CYFB, CYFC, CYFD 2011-2014
Compatible for Ford Transit Bus (FD_, FB_, FS_, FZ_, FC_) 2.2 TDCi 103KW PGFA, PGFB, UHFA, UHFB, UHFC 2007-2014
Compatible for Ford Transit Bus (FD_, FB_, FS_, FZ_, FC_) 2.2 TDCi 74KW DRFA, DRFB, DRFC, DRFD, DRFE 2011-2014
Compatible for Ford Transit Van (FA__) 2.2 TDCi 74KW DRFA, DRFB, DRFC, DRFD, DRFE 2011-2014
Compatible for Ford Transit Van (FA__) 2.2 TDCi 92KW CYFA, CYFB, CYFC, CYFD 2011-2014
Compatible for Ford Transit Van (FA__) 2.2 TDCi 103KW PGFA, PGFB, UHFA, UHFB, UHFC 2007-2014


Turbo Part Number & OEM Number:

1741779，
1946738，
786880-0006,7868805006S,786880-5006S，
786880-0012,7868805012S,786880-5012S，
786880-0021,7868805021S,786880-5021S，
786880-6,786880-21,
786880-9006S,
786880-9012S,
BK206K682GA,BK20-6K682-GA，
BK2Q6K682CA,BK2Q-6K682-CA，
BK2Q6K682GA,BK2Q-6K682-GA，
BK2Q6K682GB,BK2Q-6K682-GB，





Specification:

Turbo Model:GTB1749VK
Engine:Duratorq EURO 5
Cooling Type:Oil Cooling
Fuel Type:  Diesel

Condition: 100% Brand New
Accessories: You will get what you can see in the pictures exactly
Package Size: 15*15*15cm
Package Weight: 1880g





Package Included:

1x Turbo cartridge
2x Oil Gaskets
1x O-Ring

2x Flange Gaskets

2x Oil/ Water Port Gaskets

2x Oil Pipe Bolts

6x Stud Bolt&Nuts

1x Manual
1x Brochure
1x Sticker













Features:

* Product Material
1. Turbine housing ：Ductile iron QT450-10- temperature resistant up to 700℃
2. Steel turbine wheel：K418 alloy -  high  oxidation stability and resistance  up  to 900℃
3. Compressor housing：ZL104 aluminum with lightweight
4. Compressor wheel：Cast aluminium blades – superior air tightness & corrosion resistance

* Product
1. OEM-quality and size with little modification
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance

* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS  VSR
2.  G3-min-Flow VNT Turbo testing
3.  Advanced Actuator Tester/Programmer






Note:

* Please confirm your original turbo PART NUMBER before Purchasing
* Professional installation is highly recommended
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
