K04 Billet Wheel Turbo compatible for Audi A4 compatible for VW PASSAT 1.8T anb engine 1999 -2004 K04-015

This MaXpeedingRods part is suitable for Audi, Volkswagen applications as stated. Always check part number, year of manufacture, engine code and fitment before ordering.

Advantages

• Based on original MaXpeedingRods product information
• Suitable for direct replacement or performance upgrade

Application, specifications and compatibility

Application Suitable for Audi A4 A6 Quattro suitable for VW PASSAT 1.8T AEB/ANB/APU/AWT Upgrade Suitable for Audi A4 1.8T AEB/ANB/APU/AWT20v/AVJ 1995 - 1999 Suitable for Audi A4 Quattro 1.8T AEB/ANB/APU/AWT/AVJ 1999 -Suitable for Audi A4 Upgrade 1.8T 1995 -Suitable for Audi A6 1.8T AEB/ANB/APU/AWT 1997 - 1999 Suitable for Audi A6 Quattro1.8T AEB/ANB/APU/AWT 1999 -Suitable for VW Passat 1.8TAEB/ANB/APU/AWT 1999 -Suitable for VW Passat 1.8 Tupgrade1999 -OE-/part number53039880005, 53039700005,53039880013, 53039700013,53039880029, 53039700029,53039880025, 53039700025,53039880073, 53039700073,058145703L, 058145703LX, 058145703LV,058145703K, 058145703KX, 058145703KV058145703N,058145703NX , 058145703NV,058145703Q，058145703QX,058145703QV，058145703B, 058145703C, 058145703D，058145703E, 058145703H,Specifications Turbo model: K04, K04-0015

Engine code: AEB/ANB/APU/AWT20v/AVJ

Cooling Type：Water Cooled

Bearing Type: Floating Bearing

Horsepower: Up to 250HP

Thrust bearings: 270 Degrees

Turbo Type: Individual

Universal Fitment: No

Finish: Polished

Condition: 100% Brand New

Accessories: You will get exactly as shown in the picture above

Package Size: 26x24x23cm

Package Weight: 6020g Package included1x Turbocharger

2x Flange gaskets

2x Oil/Water port gaskets

1x Manual

1x Brochure

1x Sticker Features*Product Material

1. Turbine housing ：Silicon-Molybdenum - temperature resistant up to 850℃

2. Steel Turbine Wheel：K419 alloy - high oxidation stability and resistance up to 1000℃

3. Compressor housing：ZL104 aluminum with lightweight

4. Billet compressor wheel：forged full-machined billet aluminum compressor wheels with a larger horsepower range and better boost response

*Product Performance

1. OEM fitment turbo with upgraded material and performance

2. Excellent high temperature resistance，high efficiency and durability

3. Rich experience in turbo production and own factory

4. High-Speed oil seal ring and Precision clearance

* Technology Advantage:

1. 100% balancing Test by TURBOTECHNICSVSR3

2.G3-min-Flow VNT Turbo testing

3.Advanced Actuator Tester/Programmer Note* Please confirm your original turbo PART NUMBER before Purchasing

* Professional installation is highly recommended

* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!description

Application:

Suitable for Audi A4 A6 Quattro suitable for VW PASSAT 1.8T AEB/ANB/APU/AWT Upgrade

Suitable for Audi A4 1.8T AEB/ANB/APU/AWT20v/AVJ 1995 - 1999

Suitable for Audi A4 Quattro 1.8T AEB/ANB/APU/AWT/AVJ/BEX 1999

Suitable for Audi A4 Upgrade 1.8T 1995

Suitable for Audi A6 1.8T AEB/ANB/APU/AWT 1997 - 1999

Suitable for Audi A6 Quattro 1.8T AEB/ANB/APU/AWT 1999

Suitable for VW Passat 1.8T AEB/ANB/APU/AWT 1999

Suitable for VW Passat 1.8T upgrade 1999

Interchange Part Number:

53039880005, 53039700005,

53039880013, 53039700013,

53039880029, 53039700029,

53039880025, 53039700025,

53039880073, 53039700073,

53049880015, 5304-988-0015, 5304 988 0015,

53049700015, 5304-970-0015,5304 970 0015,

058145703L, 058145703LX, 058145703LV,

058145703J, 058145703JX, 058145703JV,

058145703K, 058145703KX, 058145703KV

058145703N,058145703NX , 058145703NV,

058145703Q，058145703QX,058145703QV

058145703B, 058145703C, 058145703D

058145703E, 058145703H,

Specifications:

Compressor :

Wheel Diameter: 50/37.5 mm

Trim: 56

Compressor Inlet: 44.5 mm

Compressor Outlet: 50 mm

Blades: 4 x 4 blades type

Turbine :

Wheel Diameter: 46/42 mm

Trim: 83.7

Blades: 12 blades

Inlet Flange: 3 Bolt Flange

Outlet Flange: 3 Bolt Flange

Turbo Model:K03 upgraded, K04

Engine: AEB/ANB/APU/AWT/AVJ/BEX

Fuel: Gasoline

Cooling Type:Water & Oil Cooling

Horsepower Rating: up to 220 HP

Bearing Type: Floating Bearing

Thrust bearings: 270 Degrees

Turbo Type: Individual

Universal Fitment: No

Finish: Polished

Condition: Brand New

Accessories: You will get exactly as shown in the picture above

Package Weight: 5300g

Package Size: 31*28*24cm

Features

1. Turbine housing: Silicon-Molybdenum alloy steel - High temperature resistance, highly stable and ductile, corrosion and crack resistant, increases durability and reliability.

2. Turbine Wheel: K419 alloy - High temperature resistance, efficiently converts engine exhaust gasses into kinetic energy, resists thermal breakdown for smooth reliable operation.

3. Billet Compressor Wheel: Forged billet aluminum CNC machined compressor wheel - High efficiency, fast response, lower fuel consumption, smooth operation.

4. Oil Seal: High-speed steel oil seal ring - Abrasion and heat resistant, protects bearings, prevents oil leakage and smoking.

NOTE:

* Please confirm your original turbo PART NUMBER before Purchasing

* Professional installation is highly recommended

* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insuff
